Maxus SC5000

The Maxus SC5000 redefines the boundaries of construction and restoration projects. This mid-heavyweight champion combines the robustness of a lifting machine with the finesse of a working platform, engineered to take your projects to heights of up to 150 meters with unmatched reliability and speed.

Product images are provided to enhance understanding and may differ from actual product appearances; please contact our team or refer to the instruction manuals for detailed information.

Key Features

Lifting Speed

7 m/min

Loading Capacity

Up to 2700 kg with single unit configurations
Up to 5000 kg with a twin unit configurations

Installation Height

Up to 150 meters and higher

Platform Length

Up to 16.9 meters with single unit configurations
Up to 40.6 meters with a twin unit configurations

Max. Free Standing Height

Up to 20 m

Customization Options

Technical Information

SC 5000 Capacity

Capacity	SC5000 Single	SC5000 Twin
Max. platform length	16.9 m	40.6 m
Max. lifting capacity / platform length	2700 kg / 4.1 m	5000 kg / 12.6 m
	2300 kg / 7.3 m	4000 kg / 20.6 m
	1900 kg / 10.5 m	3000 kg / 28.6 m
	1500 kg / 13.7 m	2200 kg / 35.0 m
	1000 kg / 16.9 m	1500 kg / 40.6 m
Maximum height with mast anchored	100 m (higher mast by request)	100 m (higher mast by request)
Max. mast height, freestanding mast with full extended outriggers with extended outriggers on one side * depending on the platform length	18 – 20 m* 13 – 18 m*	20 m* 13 – 20 m*
Max. height with top anchor	25 m	25 m
Max. anchor spacing	18 m	18 m
Vertical travel speed	7/12 m / min	7/12 m / min
Chassis drive unit speed	13 m / min
Max. allowed windspeed anchored	15.5 m/s	15.5 m/s

SC 5000 Weights and dimensions

Weights and Dimensions	SC5000 Single	SC5000 Twin
Lowest transport height	2.4 m	2.4 m
Lowest platform level	1.2 m	1.2 m
Platform section length width weight	1.61 m 1.6 m 158 kg	1.61 m 1.6 m 158 kg
Platform extensions	0 – 1.8 m 0 – 2.5 m 2.6 – 6.0 m	0 – 1.8 m 0 – 2.5 m 2.6 – 6.0 m
Mast section length width height weight	0.7 m 0.7 m 1.25 m 82 kg	0.7 m 0.7 m 1.25 m 82 kg
Lifting frame (fully equipped) length width height weight	4.1 m 1.6 m 2.0 m 1500 kg	4.1 m 1.6 m 2.0 m 2 x 1500 kg
Chassis with outriggers length width weight	5.1 m 1.93 m 1900 kg	5.1 m 1.93 m 2 x 1900 kg

SC 5000 Electrical Data

Electrical Data	SC5000 Single	SC5000 Twin
Power – lifting machinery	2 x 3,0 kW or 5,5 kW	4 x 3,0 kW or 5,5 kW
Power – travel machinery	1.1 kW	2×1.1 kW
Supply voltage/frequency	2×400/50 V/Hz	4×400/50 V/Hz
Control voltage/frequency	48/50 V/Hz	48/50 V/Hz
Max. starting current	100 A or 134 A	? A
Max. power consumption	8 kVA	16 kVA
Power supply fuses	3 x 32 A	3 x 32 A + 3 x 32 A
Outlets for hand tools voltage current	2 x 230 V 16 A	4 x 230 V 16 A

SC 5000 Safety Equipment

Safety Equipment	SC5000 Single	SC5000 Twin
Mechanical safety brake	Yes	Yes
Emergency stop push-button, top and bottom limit switches	Yes	Yes
Electromagnetic brake	Yes	Yes
Fault current relay	Yes	Yes
Safety sensor during erection	Yes	Yes
Chassis drive interlocking limit switch	Yes	Yes
Mast guard nets	Yes	Yes
Safety railing (height 1,10 m) and toeboards	Yes	Yes
Automatic platform level control system on twin mast version		Yes
Emergency lowering system	Yes	Yes
